Lub Rooj Sab Laj Hu Rau Lub Koob Yees Duab Video thiab hais lus

Khoom Taw Qhia

Hauv koj lub neej ua haujlwm niaj hnub, koj yuav xav tau lub koob yees duab hauv chav sib tham hauv microsoft. Raws li tus neeg muag khoom ntawm lub koob yees duab hauv chaw ua haujlwm, peb xav kom koj xav txog chav sib tham no hu rau lub koob yees duab video thiab hais lus. Lub koob yees duab no muaj USB video tso zis, nruab nrog 1/2. chav sib tham me me thiab nruab nrab. Nws muaj lub koob yees duab USB nrog 10x optical zoom, uas tsis yog tsuas yog sau cov duab meej thiab muag, tab sis kuj txhawb kev sib koom ua ke nyob deb. Qhov no tso cai rau nws los pab koj qhia cov ntsiab lus tseem ceeb nrog koj cov tswv cuab thaum lub rooj sib tham video, thiab ua kom muaj kev cuam tshuam los ntawm kev taug qab cov ntsiab lus ntawm lub ntsej muag ntawm cov tswv cuab.



Nta

1. Ua kom pom tseeb du: Cov khoom no siv lub lens zoo nrog stabilizer thiab nws pib-focus muaj nuj nqi, uas tuaj yeem txo jitter thiab plooj hauv lub vijtsam video thiab ua rau koj lub rooj sib tham video ruaj khov thiab du.



2. Ntau yam qauv: Peb lub koob yees duab kev sib tham yog cov nplua nuj nyob hauv cov qauv, thiab cov khoom uas muaj ntau yam specifications raug muag. Txawm hais tias koj xav tau lub koob yees duab yees duab rau lub rooj sib tham zoom, lub koob yees duab hauv chav sib tham thiab hais lus, lossis lub koob yees duab rau lub rooj sib tham zoom rau chav sib tham me me, koj tuaj yeem nrhiav cov khoom koj xav tau ntawm no.



3. Lub roj teeb lub neej ntev: Lub koob yees duab muaj lub peev xwm loj uas muaj peev xwm rov ua tau lub roj teeb, uas muaj lub sijhawm ua haujlwm ntev thiab tuaj yeem kav ntev li 9 teev lossis ntau dua ib zaug. Txawm hais tias lub hwj chim raug txiav tawm, nws yuav tsis cuam tshuam koj cov ntaub ntawv video, yog li koj tsis tas yuav txhawj xeeb tias koj lub cuab yeej yuav poob rau hauv nruab nrab ntawm lub rooj sib tham.



4. Yooj yim rau nruab: nws yooj yim heev rau nruab, tsis tsuas yog txhawb nqa ceilings, phab ntsa-mounted thiab tripods, tab sis kuj los nrog tag nrho cov tsim nyog accessories. Yog li ntawd, koj tsuas yog yuav tsum tau nruab rau ntawm lub rooj hauv chav sib tham thiab txuas mus rau cov cuab yeej tshaj lij los ntawm USB thiab lwm txoj kev sib txuas, thiab koj tuaj yeem pib lub rooj sib tham sai.





Khoom Parameter

Qauv	UV300
Sensor	1/2.9 nti CMOS
Muaj txiaj ntsig pixel	2.1 mega pixel daws teeb meem
Video system	1080p/30/25, 720p/30/25
Zoom	10 x optical zoom
Lens	f{0}}0-50.0mm
Aperture	F1.8~2.1
Kab rov tav kaum	54.8 degree (W) -5.8 degree (T)
Lub kaum sab xis	41.2 degree (W) -4.38 degree (T)
Diagonal lub kaum sab xis	67.6 degree (W) -7.15 degree (T)
FOV	51.3 degree
Video tso zis	USB 2 0
Video daws teeb meem	1080P (1920 * 1080) thiab lwm yam
Teeb liab txheem	NTSC/PAL
Preset txoj hauj lwm	64
Tswj lub davhlau ya nyob twg	RS -232, RS485
Shutter	1/30s -1/10000s, auto
Baud tus nqi	38400/9600bps
Tswj raws tu qauv	VISCA, PELCO-D, PELCO-P(RS-232, RS485)
USB raws tu qauv	UVC 1.1
Yam tsawg kawg Illumination	0.1Lux
SNR	Ntau dua lossis sib npaug li 50dB
Video encoding hom ntawv	MJPEG, YUV
Kab rov tav tig	35 0 degree (± 175 degree) 0.1 degree /s -100 degree /s
Vertical rotation	9 0 degree (± 45 degree) 0.1 degree / s -80 degree s
Fais fab mov	DC 12V / 2A
Kev siv fais fab	12W
Ua haujlwm kub	0 degree ~ +50 degree
Ua haujlwm av noo	0 ~ 95% RH
Khoom loj	247 * 165 * 170 hli
Khoom hnyav	1.46kg / 2.85kg (net / tag nrho qhov hnyav)











Cov lus qhia ntau lawm

10x optical PTZ lub rooj sib tham lub koob yees duab, txais yuav 1/2.9 nti zoo sensor, 2.1 mega pixel daws teeb meem; Yias: ± 175 degree (Max ceev 80 degree / S); Tilt: -35 degree --+55 degree (Max ceev 60 degree / s);

Siv ntau lub ntsiab lus 10x lossless optical zoom lens, nrog 51.3-degree wide angle FOV;

Txhawb infrared tswj, RS232 tswj, txhawb VISCA, PELCO-D, PELCO-P raws tu qauv.

Preset txoj hauj lwm: 10 preset ntawm IR chaw taws teeb tswj;

Keyboard maub los (RS232 / RS485); los ntawm txoj kev no, koj tuaj yeem teeb 64 presets;

Tau tshaj Win7/8/10, Mac OSX 10.7 lossis siab dua, thiab Android thiab lwm yam.

Nrog rau ntau yam kev teeb tsa, kev txhawb nqa qab nthab, phab ntsa mount thiab tripod thiab lwm yam, nws tuaj yeem yooj yim ntes koj cov duab xav tau;





Khoom tsim nyog

Peb daim ntawv pov thawj: CE, FCC, RoHS thiab lwm yam





Xa, nkoj thiab pab

Kev xa khoom:
Rau cov qauv txiav txim, peb muaj cov khoom hauv Tshuag; tib hnub shipping thaum peb tau txais qhov kev txiav txim;
Rau kev yuav khoom, peb yuav xa tuaj tsis pub dhau 3-7 hnub ua haujlwm;
Ntim:
Ua npuas ncauj ntim hauv; txheem thawv ntim sab nraum.





FAQ

Q: Yuav ua li cas peb thiaj li tau txais daim ntawv tsocai rau lub rooj sib tham hu xov tooj lub koob yees duab?

A: Hu rau peb nrog cov lus qhia tshwj xeeb: xws li cov khoom siv, tsim, qhov loj me, cov duab, xim, kom muaj nuj nqis, nto tiav, thiab lwm yam.



Q: Cov nqe lus ua lag luam thiab cov nqe lus them nqi yog dab tsi?

A: 100% T / T ua ntej; peb txhawb T / T, Western Union, PAYPAL thiab lwm yam.



Q: Koj lub sijhawm xa khoom yog dab tsi?
A: Peb lub sijhawm xa khoom zoo ib yam yog FOB Shenzhen. Peb kuj lees txais EXW, CFR, CIF, DDP, DDU thiab lwm yam. Peb yuav muab cov nqi thauj khoom rau koj thiab koj tuaj yeem xaiv qhov uas yooj yim tshaj plaws rau koj.



Q: Txoj kev shipping twg koj tuaj yeem muab tau?

A: Raws li rau Chav Sib Tham Hu Xov Tooj Yees Duab thiab Hais Lus, peb tuaj yeem muab kev xa khoom los ntawm hiav txwv, huab cua thiab nthuav qhia.



Q: Koj qhov kev pab cuam tom qab muag yog dab tsi?

A: Peb lub sijhawm lav zoo yog ob xyoos. Txhua qhov teeb meem zoo yuav daws tau rau cov neeg siv khoom txaus siab.
