MAC PC video rooj sib tham lub koob yees duab



UV800 MAC PC video lub rooj sib tham lub koob yees duab tsis tsuas yog muaj 20x optical zoom muaj nuj nqi, tab sis kuj muab ib tug kab rov tav rotation ntau yam ntawm -175 degree rau +175 degree thiab ib ntsug rotation ntau ntawm -90 degree rau +90 degree. Nyob rau tib lub sijhawm, nws tuaj yeem sib xyaw nrog Windows thiab MAC kev khiav haujlwm, thiab tseem tuaj yeem ua tau nrog ntau lub rooj sib tham software lossis video software xws li Zoom, BlueJeans, Amazon Chime, GoToMeeting, thiab lwm yam. Hais txog cov duab zoo, peb xaiv qhov siab. -zoo SONY CMOS sensor los xyuas kom meej tias lub rooj sib tham video koob yees duab tuaj yeem tso tawm 1080p cov duab zoo. Yog li ntawd, txawm tias tus neeg siv zoom hauv ob peb zaug, cov ntsiab lus tseem pom tau meej meej. Raws li kev tsim qauv, nws siv cov iav-hlau sealing thev naus laus zis los xyuas kom meej tias sab nraud huab cua thiab plua plav raug cais tawm kom ntseeg tau tias lub lens tsis pom qhov muag plooj, thiab lub lauj kaub / qaij txav tau zoo thiab ntsiag to, kom ntseeg tau tias cov rooj sib tham yuav tsis cuam tshuam los ntawm lub suab nrov.





1080P HD daws teeb meem: pom tseeb
Lub rooj sib tham usb lub koob yees duab tuaj yeem muab 1080P tag nrho HD daws teeb meem, yog li cov ntsiab lus ntawm daim duab tuaj yeem ua kom pom tseeb rau txhua tus neeg tuaj koom, uas yog qhov tseem ceeb rau kev tshaj tawm cov khoom tshiab thiab kev qhia tawm hauv thaj chaw deb.



Kev ua haujlwm PTZ du: meej txhua kauj ruam
Raws li PTZ muaj nuj nqi, lub koob yees duab kev sib tham hauv video no tuaj yeem muab kev paub zoo thiab meej. Txawm hais tias panning kom ntes tau qhov dav hauv chav saib lossis zoom rau cov ntsiab lus, txhua qhov haujlwm yuav nyob ruaj khov thiab nyob ntsiag to.



Ntau lub kaum sab xis saib: tag nrho tswj
Lub rooj sib tham lub koob yees duab rau pc no muaj lub taub hau tig. Nws tuaj yeem tig -175 degree mus rau +175 degree horizontally thiab -90 degree rau +90 degree vertically, txhais tau tias koj muaj kev tswj kom tiav lub kaum sab xis saib ntawm koj lub rooj sib tham tsis hais txog qhov chaw txwv.



Ntau qhov kev xaiv video tso zis: hloov tau yooj yim txuas
Lub koob yees duab kev sib tham hauv video no muab ntau yam kev xaiv tso zis video, suav nrog USB 3.0, HDMI thiab SDI, thiab tag nrho cov txheej txheem sib kis tau ua kom ruaj khov thiab txhais cov duab zoo. Qhov no tsim ua rau daim ntawv thov ntawm lub koob yees duab no yuav luag unlimited.



10 chaw taws teeb tswj preset txoj haujlwm: yooj yim rau kev khiav lag luam
Txij li thaum lub koob yees duab MAC lub rooj sib tham video no muaj 10 qhov chaw taws teeb tswj preset txoj haujlwm, nws txoj haujlwm ua haujlwm tau yooj yim dua. Nyob rau tib lub sijhawm, nws tuaj yeem tswj tau los ntawm cov chaw taws teeb tswj, thiab tseem tuaj yeem preset 64 txoj haujlwm los ntawm cov keyboard controller.







Multi-angle kev sib hloov
MAC PC video lub rooj sib tham lub koob yees duab txhawb nqa kab rov tav lub kaum sab xis yog: -175 degree ~ +175 degree, ntsug tig lub kaum sab xis yog: -90 degree ~ +90 degree ;

Kev tswj ntau yam

Txhawb infrared tswj, RS232 tswj, Web interface tswj, txhawb VISCA, PELCO-D, PELCO-P raws tu qauv, thiab tsis siv neeg Identifiable raws tu qauv;

Preset txoj hauj lwm

Cov neeg siv tuaj yeem teeb tsa 10 txoj haujlwm los ntawm IR chaw taws teeb tswj; 64 los ntawm cov keyboard tswj;

Yooj yim li Plug & ua si

Video tso zis: USB 3.0 ntsaws thiab ua si, HDMI/SDI thiab NDI. Leej twg tuaj yeem teeb tsa SDI lub koob yees duab no yooj yim thiab tswj kev sib tham nyob streaming;





Qauv	UV800
Sensor	1/2.9 nti CMOS
Muaj txiaj ntsig pixel	2.38 megapixel daws
Video system	1080p-30/25, 720p-30/25
Zoom	20x optical zoom
Lens	f=5 5-110 hli
Aperture	F1.6-3.5
Kab rov tav kaum	55.8 degree (W) -3.2 degree (T)
Lub kaum sab xis	32.2 degree (W) -1.8 degree (T)
Diagonal	61 degree (W) -3.64 degree (T)
FOV	55.8 degree
Video tso zis	USB 3 0
Video daws teeb meem	1080P (1920 * 1080) thiab lwm yam
Teeb liab txheem	NTSC/PAL
Preset txoj hauj lwm	64
Tswj lub davhlau ya nyob twg	RS -232, RS485
Shutter	1/30s -1/10000s, auto
Baud tus nqi	38400/9600bps
Tswj raws tu qauv	VISCA, PELCO-D, PELCO-P(RS-232, RS485)
USB raws tu qauv	UVC 1.1
Yam tsawg kawg Illumination	0.1Lux
SNR	Ntau dua lossis sib npaug li 50dB
Video encoding hom ntawv	MJPEG, YUV
Kab rov tav tig	35 0 degree (± 175 degree) 0.1 degree /s -100 degree /s
Vertical rotation	9 0 degree (± 45 degree) 0.1 degree / s -80 degree s
Fais fab mov	DC 12V / 2A
Kev siv fais fab	12W
Ua haujlwm kub	0 degree ~ +50 degree
Ua haujlwm av noo	0 ~ 95% RH
Khoom loj	247 * 165 * 170 hli
Khoom hnyav	1.46kg / 2.85kg (net / tag nrho qhov hnyav)





Q: Koj lub Hoobkas nyob qhov twg?

A: Hauv Shenzhen, Suav.



Q: Thaum twg koj lub Hoobkas tsim?

A: Txij li thaum xyoo 2013.Peb tau tshwj xeeb hauv kev tsim cov mac pc video rooj sib tham lub koob yees duab rau ntau xyoo.



Q: Yuav ua li cas txog lub sij hawm ua khoom loj?
A: 15-20 hnub ua haujlwm rau ntau lawm. Nws nyob ntawm koj qhov ntau, thiab peb yuav sim peb qhov zoo tshaj plaws kom tau raws li koj xav tau.



Q: Koj lub lag luam loj yog dab tsi?

A: Peb lub koob yees duab kev sib tham video tau raug muag rau Tebchaws Europe, North America, South America, Australia, Middle East thiab lwm lub tebchaws thiab cheeb tsam.



Lub koob yees duab lub rooj sib tham no rau pc yog tsim los coj koj lub rooj sib tham video mus rau qhov siab tshiab. Yog tias koj tab tom nrhiav rau cov kev daws teeb meem video uas tuaj yeem siv hauv tsev thiab chaw ua haujlwm, peb, ib qho ntawm lub rooj sib tham usb lub koob yees duab manufacturers thiab lwm tus neeg nyob hauv Suav teb, tuaj yeem muab cov khoom zoo rau koj! Tau ntau xyoo peb tau muab cov koob yees duab rau ntau lub lag luam thiab cov tib neeg kom haum rau cov kev xav tau sib txawv thiab lawv tau txais txiaj ntsig zoo. Tiv tauj peb tam sim no kom tau txais tus nqi zoo tshaj plaws ntawm lub rooj sib tham video koob yees duab thiab paub txog nws cov txiaj ntsig!
